PVDF Male Barb Block Connector (with O-Ring)

Brand:

  • Tefen Fittings


LEARN MORE

PVDF is a special natural white shade of color plastic raw material. Fittings made of PVDF can function well, even when exposed to a wide range of temperatures and high corrosive chemicals.
Working pressure: Up to 14 BAR | (200 psi) at 20 ºC
Temperature: -20 ºC to -120 ºC (subject to application)

Cat. No.OD (inch)Thread (BSPP)L (mm)SWColourO-ring
22F568040211/4"1/8"27.116White & Navy BlueSiliconeBUY NOW
22F568040411/4"1/4"30.919.4White & Navy BlueSiliconeBUY NOW
