| Cat. No. | OD (inch) | Thread (BSPP) | L (mm) | SW | Colour | O-ring | |
|---|---|---|---|---|---|---|---|
| 22F56804021 | 1/4" | 1/8" | 27.1 | 16 | White & Navy Blue | Silicone | BUY NOW |
| 22F56804041 | 1/4" | 1/4" | 30.9 | 19.4 | White & Navy Blue | Silicone | BUY NOW |
PVDF Male Barb Block Connector (with O-Ring)
Brand:
PVDF is a special natural white shade of color plastic raw material. Fittings made of PVDF can function well, even when exposed to a wide range of temperatures and high corrosive chemicals.
Working pressure: Up to 14 BAR | (200 psi) at 20 ºC
Temperature: -20 ºC to -120 ºC (subject to application)
