Working pressure: Up to 14 BAR (200 psi) at 20 ºC
Temperature: 4 ºC – 90 ºC (subject to application)
| Cat. No. | OD (mm) | M (BSPT) | L (mm) | L1 (mm) | Colour | |
|---|---|---|---|---|---|---|
| 22047146028 | 6 | 1/8" | 46.8 | 22.6 | Blue | BUY NOW |
| 22047146048 | 6 | 1/4" | 46.8 | 26.8 | Blue | BUY NOW |
| 22047148028 | 8 | 1/8" | 46.8 | 22.6 | Blue | BUY NOW |
| 22047148048 | 8 | 1/4" | 46.8 | 26.8 | Blue | BUY NOW |
| 22047148068 | 8 | 3/8" | 47.2 | 29.4 | Blue | BUY NOW |
| 22047152048 | 12 | 1/4" | 67 | 31.6 | Blue | BUY NOW |
| 22047152068 | 12 | 3/8" | 67 | 32 | Blue | BUY NOW |
| 22047152088 | 12 | 1/2" | 67 | 36 | Blue | BUY NOW |
| 22047146042 | 6 | 1/4" | 46.8 | 26.8 | Black | BUY NOW |
| 22047148022 | 8 | 1/8" | 46.8 | 22.6 | Black | BUY NOW |
| 22047148042 | 8 | 1/4" | 46.8 | 26.8 | Black | BUY NOW |
| Cat. No. | OD (inch) | Thread (BSPT) | L (mm) | L1 (mm) | Colour | |
|---|---|---|---|---|---|---|
| 22047104028 | 1/4" | 1/8" | 46.8 | 22.6 | Navy Blue | BUY NOW |
| 22047104048 | 1/4" | 1/4" | 46.8 | 26.8 | Navy Blue | BUY NOW |
| 22047105028 | 5/16" | 1/8" | 46.8 | 22.6 | Navy Blue | BUY NOW |
| 22047105048 | 5/16" | 1/4" | 46.8 | 26.8 | Navy Blue | BUY NOW |
| 22047105068 | 5/16" | 3/8" | 47.2 | 29.4 | Navy Blue | BUY NOW |
| 22047108048 | 1/2" | 1/4" | 67 | 31.6 | Navy Blue | BUY NOW |
| 22047108068 | 1/2" | 3/8" | 67 | 32 | Navy Blue | BUY NOW |
| 22047104041 | 1/4" | 1/4" | 46.8 | 26.8 | White | BUY NOW |
